GP ELITE Single 12" High Output XL Glue it & Screw It Sub Enclosure

GP ELITE Single 12" High Output XL Glue it & Screw It Sub Enclosure

Regular price $259.99 USD
Regular price Sale price $259.99 USD
Sale Sold out

Product Description

GP Elite Advanced Options

*Assembly Required*

NOTE* Below is estimated enclosure dimensions. Tuning will change the enclosure sizes slightly. Based off your options chosen, if anything is drastically different from the dimensions noted below, we will call you to verify fitment.

_______________________________________________

___________________________________

37hz

Box External Dimensions
Width x Height x Depth
30.00" x 14.00" x 15.57"
Material Thickness 0.75"
Net Internal Volume 2.25 ft3
Tuning Frequency 37 Hz
Port Area 36.00 inch2
Port Inlet
Width x Height
2.88" x 12.50"
Port Length 24.16"

___________________________________

35hz

Box External Dimensions
Width x Height x Depth
30.00" x 14.00" x 16.08"
Material Thickness 0.75"
Net Internal Volume 2.25 ft3
Tuning Frequency 35 Hz
Port Area 36.00 inch2
Port Inlet
Width x Height
2.88" x 12.50"
Port Length 27.86"

___________________________________

33hz

Box External Dimensions
Width x Height x Depth
30.00" x 14.00" x 16.70"
Material Thickness 0.75"
Net Internal Volume 2.25 ft3
Tuning Frequency 33 Hz
Port Area 36.00 inch2
Port Inlet
Width x Height
2.88" x 12.50"
Port Length 32.25"

___________________________________

31hz

Box External Dimensions
Width x Height x Depth
30.00" x 14.00" x 17.47"
Material Thickness 0.75"
Net Internal Volume 2.25 ft3
Tuning Frequency 31 Hz
Port Area 36.00 inch2
Port Inlet
Width x Height
2.88" x 12.50"
Port Length 37.52"

___________________________________

29hz *Due to the port length, the 29hz model is 7" wider*

Box External Dimensions
Width x Height x Depth
37.00" x 14.00" x 15.12"
Material Thickness 0.75"
Net Internal Volume 2.25 ft3
Tuning Frequency 29 Hz
Port Area 36.00 inch2
Port Inlet
Width x Height
2.88" x 12.50"
Port Length 43.92"
