GP ELITE Dual 8" High Output Glue it & Screw It Sub Enclosure

Product Description

*Assembly Required*

NOTE* Below is estimated enclosure dimensions. Tuning will change the enclosure sizes slightly. Based off your options chosen, if anything is drastically different from the dimensions noted below, we will call you to verify fitment.

37hz

Box External Dimensions Width x Height x Depth	32.00" x 11.00" x 17.68"
Material Thickness	0.75"
Net Internal Volume	2.00 ft3
Tuning Frequency	37 Hz
Port Area	32.00 inch2
Port Inlet Width x Height	3.37" x 9.50"
Port Length	24.59"

________________________________________________________________________________________________

35hz

Box External Dimensions Width x Height x Depth	32.00" x 11.00" x 18.21"
Material Thickness	0.75"
Net Internal Volume	2.00 ft3
Tuning Frequency	35 Hz
Port Area	32.00 inch2
Port Inlet Width x Height	3.37" x 9.50"
Port Length	28.29"

________________________________________________________________________________________________

33hz

Box External Dimensions Width x Height x Depth	32.00" x 11.00" x 18.86"
Material Thickness	0.75"
Net Internal Volume	2.00 ft3
Tuning Frequency	33 Hz
Port Area	32.00 inch2
Port Inlet Width x Height	3.37" x 9.50"
Port Length	32.69"

________________________________________________________________________________________________

31hz

Box External Dimensions Width x Height x Depth	32.00" x 11.00" x 19.68"
Material Thickness	0.75"
Net Internal Volume	2.00 ft3
Tuning Frequency	31 Hz
Port Area	32.00 inch2
Port Inlet Width x Height	3.37" x 9.50"
Port Length	37.96"

________________________________________________________________________________________________

29hz

Box External Dimensions Width x Height x Depth	34.00" x 11.00" x 19.53"
Material Thickness	0.75"
Net Internal Volume	2.00 ft3
Tuning Frequency	29 Hz
Port Area	32.00 inch2
Port Inlet Width x Height	3.37" x 9.50"
Port Length	44.36"
