GP ELITE Single 10" High Output Glue it & Screw It Sub Enclosure
GP ELITE Single 10" High Output Glue it & Screw It Sub Enclosure
Regular price
$204.99 USD
Regular price
Sale price
$204.99 USD
Unit price
/
per
Couldn't load pickup availability
Product Description
GP Elite Advanced Options
NOTE* Below is estimated enclosure dimensions. Tuning will change the enclosure sizes slightly. Based off your options chosen, if anything is drastically different from the dimensions noted below, we will call you to verify fitment.
________________________________
37hz
Box External Dimensions Width x Height x Depth |
22.00" x 13.00" x 15.88" |
Material Thickness | 0.75" |
Net Internal Volume | 1.40 ft3 |
Tuning Frequency | 37 Hz |
Port Area | 21.00 inch2 |
Port Inlet Width x Height |
1.83" x 11.50" |
Port Length | 23.95" |
________________________________
35hz
Box External Dimensions Width x Height x Depth |
22.00" x 13.00" x 16.35" |
Material Thickness | 0.75" |
Net Internal Volume | 1.40 ft3 |
Tuning Frequency | 35 Hz |
Port Area | 21.00 inch2 |
Port Inlet Width x Height |
1.83" x 11.50" |
Port Length | 27.42" |
________________________________
33hz
Box External Dimensions Width x Height x Depth |
22.00" x 13.00" x 16.94" |
Material Thickness | 0.75" |
Net Internal Volume | 1.40 ft3 |
Tuning Frequency | 33 Hz |
Port Area | 21.00 inch2 |
Port Inlet Width x Height |
1.83" x 11.50" |
Port Length | 31.54" |
________________________________
31hz
Box External Dimensions Width x Height x Depth |
30.00" x 13.00" x 13.15" |
Material Thickness | 0.75" |
Net Internal Volume | 1.40 ft3 |
Tuning Frequency | 31 Hz |
Port Area | 21.00 inch2 |
Port Inlet Width x Height |
1.83" x 11.50" |
Port Length | 36.49" |
________________________________
