GP ELITE Single 10" High Output Glue it & Screw It Sub Enclosure

GP ELITE Single 10" High Output Glue it & Screw It Sub Enclosure

Regular price $204.99 USD
Regular price Sale price $204.99 USD
Sale Sold out

Product Description

GP Elite Advanced Options

NOTE* Below is estimated enclosure dimensions. Tuning will change the enclosure sizes slightly. Based off your options chosen, if anything is drastically different from the dimensions noted below, we will call you to verify fitment.

________________________________

37hz

Box External Dimensions
Width x Height x Depth
22.00" x 13.00" x 15.88"
Material Thickness 0.75"
Net Internal Volume 1.40 ft3
Tuning Frequency 37 Hz
Port Area 21.00 inch2
Port Inlet
Width x Height
1.83" x 11.50"
Port Length 23.95"

________________________________

35hz

Box External Dimensions
Width x Height x Depth
22.00" x 13.00" x 16.35"
Material Thickness 0.75"
Net Internal Volume 1.40 ft3
Tuning Frequency 35 Hz
Port Area 21.00 inch2
Port Inlet
Width x Height
1.83" x 11.50"
Port Length 27.42"

________________________________

33hz

Box External Dimensions
Width x Height x Depth
22.00" x 13.00" x 16.94"
Material Thickness 0.75"
Net Internal Volume 1.40 ft3
Tuning Frequency 33 Hz
Port Area 21.00 inch2
Port Inlet
Width x Height
1.83" x 11.50"
Port Length 31.54"

________________________________

31hz

Box External Dimensions
Width x Height x Depth
30.00" x 13.00" x 13.15"
Material Thickness 0.75"
Net Internal Volume 1.40 ft3
Tuning Frequency 31 Hz
Port Area 21.00 inch2
Port Inlet
Width x Height
1.83" x 11.50"
Port Length 36.49"

________________________________
